🤖🚫 Verify human

This article explains how the anti-bot feature is implemented in the Gift Boxes game — using Cloudflare Turnstile for human verification on both the frontend and backend, and EIP-712 signature verification on the smart contract side.

Frontend Turnstile

Embed widget on frontend, explicit rendering.

Get the site key on cloudflare dashboard, go to https://dash.cloudflare.com/, sign in, select Turnstile on sidebar.

Embed it on nextjs app.

Turnstile type

// global.d.ts
declare global {
  interface Window {
    turnstile?: {
      render: (
        element: HTMLElement | string,
        options: {
          sitekey: string;
          size?: "normal" | "compact" | "invisible";
          callback?: (token: string) => void;
          "error-callback"?: () => void;
          "expired-callback"?: () => void;
        }
      ) => string; // returns widgetId
      execute: (widgetId: string) => void;
      remove: (widgetId: string) => void;
    };
  }
}
export {};

Turnstile component

Embed and control Turnstile with execute and remove actions.

import {
  useEffect,
  useRef,
  forwardRef,
  useImperativeHandle,
} from "react";

export interface TurnstileRef {
  execute: () => Promise<string>;
  remove: () => void;
}

const siteKey = "0x4AA...f6"; // Your Turnstile site key

const Turnstile = forwardRef<TurnstileRef, {}>(
  ({}, ref) => {
    const containerRef = useRef<HTMLDivElement>(null);
    const widgetIdRef = useRef<string | null>(null);

    useEffect(() => {
      // Load Turnstile script if not already loaded
      if (!document.querySelector("#cf-turnstile")) {
        const script = document.createElement("script");
        script.src = "https://challenges.cloudflare.com/turnstile/v0/api.js?render=explicit";
        script.async = true;
        script.defer = true;
        script.id = "cf-turnstile";
        document.body.appendChild(script);
      }
    }, []);

    // Expose methods to parent
    useImperativeHandle(ref, () => ({
      execute: () => {
        return new Promise<string>((res, rej) => {
          if (window.turnstile && containerRef.current) {
            widgetIdRef.current = window.turnstile.render(containerRef.current, {
              sitekey: siteKey,
              size: "normal",
              callback: (token) => res(token),
              "error-callback": () => rej('error'),
              "expired-callback": () => rej('expired'),
            });
          } else {
            rej('turnstile not loaded');
          }
        })

      },
      remove: () => {
        if (widgetIdRef.current && window.turnstile) {
          window.turnstile.remove(widgetIdRef.current);
        }
      },
    }));

    return (
      <div
        ref={containerRef}
        style={{
          position: 'fixed',
          top: '50%',
          left: '50%',
          transform: 'translate(-50%, -50%)'
        }}
      ></div>
    );
  }
);

Turnstile.displayName = "Turnstile";
export default Turnstile;

Usage

import { useAccount } from 'wagmi'
// ...
import Turnstile, { TurnstileRef } from '@/components/Turnstile'

export const GameComponent = () => {
  const turnstileRef = useRef<TurnstileRef>(null)
  const { address } = useAccount()

  const doAction = useCallback(async () => {
    try {
      const token = await turnstileRef.current?.execute()
      if (token) {
        const rs = await verifyHuman(address, token)  // check the token on backend
        if (rs.success) {
          // if token verified success
          //  - get the signature from backend
          //  - interact with contract with that valid signature
          const { signature } = rs.signData
          // call contract with signature
        }
      }
    } catch (e) {
      console.log('Turnstile execute error', e)
    } finally {
      // remove the turnstile to prepare for next action
      turnstileRef.current?.remove()
    }
  }, [])

  return (
    <>
      //... GameUI Element
      <Turnstile ref={turnstileRef} />
    </>
  )
}

Backend

On server-side:

• Verify the turnstile token from client on Cloudflare api.
• Generate signature using Viem.

Verify turnstile token

Get the Secret Key on Cloudflare dashboard. Validate the token

interface TurnstileResponse {
  success: boolean;
  'error-codes'?: string[]; // optional
}

// get turnstile secret key
const SECRET_KEY = process.env.SECRET_KEY

export async function validateTurnstile(token: string): Promise<TurnstileResponse> {
  const formData = new FormData();
  // secret key from dashboard
  formData.append('secret', SECRET_KEY);
  // token from client
  formData.append('response', token);

  try {
    const response = await fetch('https://challenges.cloudflare.com/turnstile/v0/siteverify', {
      method: 'POST',
      body: formData
    });

    const result = (await response.json()) as TurnstileResponse;
    console.log('Turnstile validation result:', result);

    return result;
  } catch (error) {
    console.error('Turnstile validation error:', error);
    return { success: false, 'error-codes': ['internal-error'] };
  }
}

Generate signature

Generate the signature using the signer private key, return it to client.

Viem signTypedData

import { privateKeyToAccount } from 'viem/accounts'

export interface SignatureResponse {
  user: Address
  deadline: number
  signature: `0x${string}`
}

// get the signer key
const signerPrivateKey = process.env.SOME_KEY

export async function generateSignature(user: Address): Promise<SignatureResponse> {
  const deadline = Math.floor(Date.now() / 1000) + 300
  const signAccount = privateKeyToAccount(signerPrivateKey)
  const signature = await signAccount.signTypedData({
    domain: {
      name: 'PixelGames Token Gift Box',  // must match the value used in contract
      version: '1', // must match the value used in contract
      chainId: 8453,  // base mainnet chain id
      verifyingContract: GiftContractAddress, // contract address
    },
    // must match type in contract
    types: {
      Permit: [
        { name: 'user', type: 'address' },
        { name: 'deadline', type: 'uint256' },
      ],
    },
    primaryType: 'Permit',
    message: {
      user,
      deadline: BigInt(deadline)
    },
  })

  return { user, deadline, signature }
}

EIP-712 Signature

On contract side, we verify the signature using EIP712 utility from openzeppelin.

import { EIP712 } from "@openzeppelin/contracts/utils/cryptography/EIP712.sol";
import { ECDSA } from "@openzeppelin/contracts/utils/cryptography/ECDSA.sol";

contract PixelGift is ..., EIP712 {
  // must match types when create signature with viem
  bytes32 private constant _PERMIT_TYPEHASH =
    keccak256("Permit(address user,uint256 deadline)");
  // signer, to verify human
  address public signer;

  // must match values when create signature with viem
  constructor() EIP712("PixelGames Token Gift Box", "1") {}

  function claimBox(uint16 position, uint256 deadline, bytes calldata signature) public {
    // ...
    if (signer != address(0)) {
      _validateClaim(msg.sender, deadline, signature);
    }
    // ...
  }

  /**
  * @notice Helper to check whether a signature is valid
  */
  error InvalidClaimSignature();
  error ClaimExpired();

  function _validateClaim(address user, uint256 deadline, bytes calldata signature) internal view {
    if (block.timestamp > deadline) revert ClaimExpired();
    bytes32 structHash = keccak256(abi.encode(_PERMIT_TYPEHASH, user, deadline));
    bytes32 digest = _hashTypedDataV4(structHash);

    address recovered = ECDSA.recover(digest, signature);
    if (recovered != signer) revert InvalidClaimSignature();
  }
}

With the signer’s private key kept secure, the claimBox function is effectively protected from bots using Cloudflare Turnstile and EIP-712 signatures.
